Product description
Parameters

Introduction

The new generation digital stepper motor driver based on a 32bit DSP processor, combination of the anti-resonance,low noise, microstep and low temperature rise technology significantly improve the performance of the stepper motor,has low noise, small vibration, low temperature rise and highspeed torque. The driver use online adaptive PID technology, without manual adjustment can be automatically generated optimal parameters for different motors, and achieve the best performance.



Features

1.High performance, low price.

2.Max response frequency up to 2000KHz.

3.Micro-step.

4.Low temperature rise, smooth motion.

5.Automatic idlecurrent reduction.

6.Online adaptive PID technology.

7.Optical isolating signals I/O.



Applications

It is suitable for a variety of small scale automation equipment and instruments, such as laser process equipment, engraving machines, medical equipment, measuring equipment, the electronic processing equipment, textile and garment equipment and so on. It always performs well when applied for equipment which requires for low vibration, low noise, high precision and highvelocity.



Selection table

a



Digital drives order information

CWD556

Current(A):2.5-5.6

VoltageV):20VDC-50VDC

Matching motors:Two-phase, four-phase hybrid stepper motors below 5.6A.

a a

CWD856

Current(A):2.1-5.6

VoltageV):20VDC-80VDC

Matching motors:Two-phase, four-phase hybrid stepper motors below 5.6A.

a a

CWD860

Current(A):2.4-7.2

VoltageV):20VDC-80VAC 24VDC-110VDC

Matching motors:Two-phase, four-phase hybrid stepper motors below 7.2A.

a a

CWD860H

Current(A):2.4-7.2

VoltageV):20VDC-60VAC 24VDC-90VDC

Matching motors:Two-phase, four-phase hybrid stepper motors below 7.2A.

a a

CWD882

Current(A):1.8-8.2

VoltageV):24VDC-90VDC

Matching motors:Two-phase, four-phase hybrid stepper motors below 8.2A.

a a

CWD1182

Current(A):2.2-8.2

VoltageV):80VDC-150VDC

Matching motors:Two-phase, four-phase hybrid stepper motors below 8.2A.

a a

CWD3M683

Current(A):3.2-8.3

VoltageV):20VDC-60VDC

Matching motors:Two-phase, four-phase hybrid stepper motors below 8.3A.

a a

CWD3M860

Current(A):2.4-7.2

VoltageV):20VDC-60VAC 24VDC-90VDC

Matching motors:Two-phase, four-phase hybrid stepper motors below 7.2A.

a a
