CWD856 stepper motor driver

Retail price
Market price
Number of views:
Product serial number
Product description

一、 Introduction

1. Descriptions

CWD856 is a new generation hybrid servo driver, it uses the 32-bit DSP processor, the internal integrates the technology of the anti-resonance, low noise, micro-step, low temperature rise ,so that dramatically improve the performance of the stepper motor,with some characteristics of low noise, small vibration, low temperature and high-speed torque . The driver's interior use the adaptive PID technology, without manual adjustment can automatically generate the optimal parameters for different motor, the motor runs to achieve the best performance.
Drive voltage is DC 80-130DAC, for various types of two-phase hybrid closed loop stepping motor which current is less 8.0A , with automatic semi-flow, self-test, over-voltage, under-voltage and over-current protection.

2. Features

• high performance, low price

• micro-step

• Automatic idle-current reduction

• Optical isolating signal I/O

•Max response frequency up to 70Kpps

• Low temperature rise, smooth motion

• Online adaptive PID technology


CWD856 is a low-cost, high-performance servo systems, suitable for a variety of large-scale automated equipments and instruments, such as low-cost, low vibration, noise, high-precision, high-speed devices, And it is ideal for applications where the equipment uses a belt-drive mechanism or otherwise has low rigidity and you don't want it to vibrate when stopping.

4. Electrical parameters

二、 Parameter settings

1. Current setting

2. Semi-flow settings

Users can set the semi-streaming capabilities of driver through SW4 . OFF indicates half the quiescent current to dynamic current, 0.5 seconds after the  pulse stops current automatically reduced to half; ON represents the static and dynamic current is the same current. SW4 should be set to OFF, so that the drive motor to reduce heat and improve reliability.

3. Subdivision setting

三、 Interface wiring instructions

1. Control signal Connector(CN1)

2. Power and Motor Connector

3.The interface circuit of control signal


四、Problems and Solutions

五、 Mechanical Specifications (unit: mm(inch),1 inch = 25.4mm)





Scan the QR code to read on your phone
We could not find any corresponding parameters, please add them to the properties table
