Three Phase Stepper Motors
Introduction
After years of research and summary for the universal demand of the motion control in various areas of the industrial automation,we CW motor carefully planned the stepper motor production line.CW hybrid stepper motor use the high quality cold rolled silicon steel sheet and high temperature perma - nent magnet materials.And we adopt the unique leading magnetic circuit design proposal in the industrial area.Our motor has the characteristic of high running torque, low tem- perature rising, high reliability and so on.It has good internal damping characteristics, no obvious oscillation area and operate smooth.
Applications
At present, the CW products are widely used in the automa-tion equipment, such as engraving machine, laser machine,CNC machine, Medical Equipment,the electronic processing equipment, textile & garment machinery, etc.
Features
The number of phases of the motor refers to the number of coils inside the motor. The two-phase stepper motor is composed of two coils, while the three-phase stepper motor is composed of three coils.
The three-phase motor is generally a large motor, so the size is generally larger than that of the two-phase motor, which also determines that the three-phase stepper motor runs more smoothly than the two-phase motor.
The three-phase stepper motor has good high-speed performance (harder characteristics), and has a smaller step angle and better accuracy than the two-phase stepper motor. Since the torque decreases slowly with the increase of speed, it is usually used in occasions where high precision is required.
Name Rule
CW X1 BH X2 X3- X4X5- X6
CW: Changzhou Chuangwei Motor&Electric Apparatus Co., Ltd
X1: Motor frame size
BH: Hybrid stepper motor
X2: 1、If lack, it means it is two phase(four phase)regular torque
motor. The Step Angleis 1.8°
X3: Body length of the motor
X4: Motor current, three digits
X5: Motor winding and connection mode
X6: The manufacturer serial number
Note: 4 lead wire indicates A, 6 lead wire indicatse B, 8 lead wire indicates C, 5 lead wire indicates D, 3 lead wire indicates E.
42BHP Mechanical Specifications
42BHP Electrical Specifications
57BHP Mechanical Specifications
57BHP Electrical Specifications
60BHP Mechanical Specifications
60BHP Electrical Specifications
86BHP Mechanical Specifications
86BHP Electrical Specifications
110BHP Mechanical Specifications
110BHP Electrical Specifications
