CWD3M2208 stepper motor driver

Retail price
Market price
Number of views:
Product serial number
Product description

一、 Introduction

1. Descriptions

The CWD3M2208 is a new generation digital 3-phase stepper motor driver, based on a 32-bit DSP processor, combination of the anti-resonance, low noise, micro-step and low temperature rise technology significantly improve the performance of the stepper motor, has low noise, small vibration, low temperature rise and high-speed torque. The driver use online adaptive PID technology, without manual adjustment can be automatically generated optimal parameters for different motors, and achieve the best performance.
Supply voltage range from 110VAC to 220VAC, suitable for driving various 3-phase hybrid stepping motors which phase current below 8.2A. The microstep can be set from full step to 40000steps/rev and the output current can be set form 2.2A to 8.2A; with automatic idle-current reduction, self-test, overvoltage, under-voltage and over-current protection.

2. Features

• high performance, low price

• micro-step

• Automatic idle-current reduction

• Optical isolating signal I/O

•Max response frequency up to 70Kpps

• Low temperature rise, smooth motion

• Online adaptive PID technology


Suitable for a variety of large-scale automation equipments and instruments. For example: labeling machine, cutting machine, packaging machine, plotter, engraving machine, CNC machine tools and so on. It always performs well when applied for equipment which requires for low-vibration, low-noise, high-precision and high-velocity.

4. Electrical parameters


二、 Current and microstep Setting

1. Current setting

2. Standstill Current Setting

SW4 is used for standstill current setting. OFF meaning that the standstill current is half of the dynamic current; and ON meaning that standstill current is the same as the selected dynamic current. Usually the SW4 is set to OFF, in order to reduce the heat of the motor and driver.

3. Microstep Setting

三、 Connectors and Pin Assignment

1. Control signal Connector

2. Power and Motor Connector

3.The interface circuit of control signal


四、Problems and Solutions

五、Mechanical Specifications (unit: mm(inch),1 inch = 25.4mm)
